LS – EP63
Di – Electric Panel Handle Lockout with small padlock
Locking holes : 10 numbers each side base : 39.4mm / 57.7mm
Plastic strip : (L) 432mm X (W) 19.10mm.
LS – EP63
Di – Electric Panel Handle Lockout with small padlock
Locking holes : 10 numbers each side base : 39.4mm / 57.7mm
Plastic strip : (L) 432mm X (W) 19.10mm.
Detail
• Material : ABS base + Steel / polypropylene strip
• Accepts shackle maximum up to : 8mm
• Locking holes : 10 numbers each side
• Base Size : 39.4mm / 57.7mm
• Plastic Strip Size : length 432mm X width 19.10mm
• Four holes of 2.2mm provided to fix it up with screw if require.
• Device is used to lockout all kind of levers / handles connected to
the electrical panel that is having no locking provision.
• For installation fix the sticky round yellow base (with high quality 3M
adhesive) rigidly then tighten the metallic / plastic strip accordingly
to freeze the movement oil operating lever / handle, & place the
padlock and tag.
Product Application
- When & Where should use LOTO?
- Daily maintenance, adjustment, cleaning, inspection and commissioning for equipment. Enter into the limited space, hot work, dismantling work and so on in the tower, tank, electrified body, kettle, heat exchanger, pumps and other facilities.
- Operation involving high voltage. ( including the operation under the high-tension cable )
- Operation require closing the safety system temporary.
- Operation during maintenance and commissioning of non-processing.
